PQ3220 PQ Type High Frequency Transformer Manufacture Customized DW6442
1. High quality and Competitive price
2. Excellent after-sale service
3. High-temperature resistant
5. High efficiency of over 95%
6. Working frequency range 20kHZ-500kHZ
7. High isolation strength
8. Lower profile and weight
9. high power density
10. Operating temperature -40℃to+125℃
11. Custom designs available
12. Supply samples free with the short delivery time
13. Suitable for a wide range of switching power supply/power transformer/ LED driver transformer/current transformer/distribution transformer
14. Welcome to visit our factory.
1. Drawing (Unit: mm)
2. Environmental Conditions
- Storage Temperature: -40--85˚C；
- Enviornmental Temperature: -40―85˚C;
- Operating Temperature: 130˚C MAX;
- Relative Humidity: 5%-95%;
- Long Term Durability Test.
3. Electrical Specification
| Item | Unit | Test Lead | Test Condition | MIN | NOR | MAX |
| Inductance Value | µH | 3-1 | 100KHz,0.3V, Ser | 325 | 350 | 375 |
| Leakage Inductance | µH | 3-1 | 100KHz,0.3V, Ser | / | / | 11 |
| Q Value | / | 3-1 | 100KHz,0.3V, Ser | 150 | / | / |
Dielectric
Strength | mA | N1—N2,N3 | 3750Vdc,60s | / | / | 1 |
| mA | N1—Core | 3750Vdc,60s | / | / | 1 |
| mA | N2,N3－Core | 500Vdc,60s | / | / | 1 |
| Direct Current Resistance | mΩ | 3-1 | 25℃ | / | / | 210 |
| mΩ | 12,11-10,9 | 25℃ | / | / | 8.0 |
| mΩ | 10,9-7,8 | 25℃ | / | / | 9.0 |
| Insulation Resistance | MΩ | Np-Ns | 500Vdc | 100 | / |
/
|
4. Two Core Edging Process for Transformer
Use about 23mm wide tape to wrap 1 layer along the edge of the magnetic core, the corner of the tape should not be damaged.
Shenzhen Dowis Electronics Co., Ltd. is a professional manufacturer of electronic transformers, inductors, and filters integrating R&D, production, and sales. It is a national high-tech enterprise and has passed the IATF16949:2016 automotive industry quality management system certification, the product has passed the "UL""CQC" and other safety certifications. The products are widely used in communication equipment, new energy vehicles, industrial control equipment, high-power LED drives, and other market areas. The industry has high visibility. In addition to the domestic market, but also exported to many countries in Europe and the United States.
In order to further expand production capacity, it has set up a special test area construction area in Zhaoqing YueGui cooperation in 2018 of 14000 square meters of manufacturing center named ZhaoQing Sheng Xiang electronic technology co., Ltd. Its management technical team has rich experience in cooperating with customers from well-known domestic enterprises and overseas. The design of products can fully follow customer’s needs and services with a good quality control system, and it has been recognized by many famous enterprises as the core supplier. We look forward to cooperating with you.
